4K high performance single board computer (RK3399)



Model: SBC3100

Category:

Exhibitor: IC NEXUS CO., LTD.

Booth No: N931



Characteristic



Description
- High performance 2xCortex-A72 4xCortex-A53@2GHZ
- Multiple display interfaces, USB3.0 type-C
- Android 7.x / Ubuntu 16.04
- (optional) LVDS display module
- (optional) HDMI input module
- (optional) 4xCOM module
Specification
CPU: Rockchip RK3399 (2x ARM Cortex-A72 4x ARM Cortex-A53)

OS: Android7.0/Ubuntu

RAM: 1GB/2GB/4GB DDR

Flash:8GB/16GB

Display Interface:
- 1 × HDMI 2.0 (4Kx2K @60fps)
- 1 × DisplayPort 1.2 (4Kx2K @60fps)
- 1 × eDP 1.3 (2560※1600 @60fps)
- 1 × MIPI-DSI (2560※1600 @60fps)

MIPI:
- 1 × CSI 1x DSI 1x (CSI or DSI)

Touch Screen Interface:
- 1 × Capacitive Touch Screen Interface (I2C)

Audio Interface:
- 1 × mic/earphone combo connector 2x speaker connector

USB 2.0 Host:
- 2 × USB 2.0 type-A 1x USB 2.0 pin header

USB 3.0 Host:
- 2 × USB 2.0 type-A 2x USB 2.0 pin header

Type-C:
USB 3.0 OTG / DisplayPort 1.2

SD Card slot:
- 1 × microSD

Ethernet:
- 1 × 10/100/1000 Mbps (RJ-45)

WiFi/BT (optional):
WiFi 802.11 b/g/n Bluetooth 4.0

3G/LTE Modem:
3G/LTE socket (mPCIe form factor) microSIM socket

Sensor (optional):
3-axis Accelerometer 3-axis Gyroscope

Buzzer:
- 1 × Buzzer

GPIO:
8-bit input/output

miniPCIe:
- 1 × miniPCIe

Console port:
- 1 × UART (console / debug)

I2C port:
- 1 × I2C master port

IR:
- 1 × IR receiver

Power Input:
DC 9V - 36V

Dimension:
129g (including heatsink)
